• Economical, reliable alternative to ball valves
• Dependable low-torque, quarter-turn operation
• Simple, compact design to deliver full flow and positive shutoff
• Available in a variety of materials, including stainless steel, brass, and lightweight PFA

Instrument Plug Valves

Options

• Handle colors: Dark green is standard. Black, blue, and red are available.
• O-Ring materials: PTFE-coated fluorocarbon FKM is standard. Kalrez®,PTFE-coated Buna N, PTFE-coated ethylene propylene, and PTFE-coated neoprene are available.
• Downstream Vents: Vented plug and valve body allow pressure release to atmosphere when the valve is closed.
• Metal handles: choose 300 series stainless steel or aluminum material.
• Locking Handles: lever locks to plate to secure valve open or closed.
• Panel Mounting

PFA Plug Valves

Catalog

Features

• Quarter-turn operation and full flow design
• Light in weight
• High-purity PFA material with low extractables for chemical\resistance
• 1/4 in. Swagelok® PFA tube fitting end connections for consistent performance
• Panel Mounting

CAD Files and Sales Drawings

Choose from more than 1 million Swagelok CAD templates and sales drawings in multi-lingual formats CAD templates are available in a variety of 2D or 3D file formats. Sales drawings are available in .pdf format. Search based on product names or part numbers.

EXPLORE CAD FILES
